CRBS01A*, B*, D*, F*, K*

CRBS01A* Non-environmental, less grommet
 CRBS01B* Environmental with grommet
Shell
Size		 Front View Side View
Q
Max		 A
+.000[+0.00]
-.006[-0.15]		 D
Min.		 K
±.008[±0.2]		 L
Max.		 M
+.016[+0.4]
-.000[-0.0]		 V
Thread Class
2A
10SL .886 [22.50] .717 [18.20] .323 [8.20] .110 [2.80] 1.693 [43.00] .559 [14.20] 5/8-24 UNEF
14S 1.161 [29.50] .969 [24.60] .437 [11.10] .126 [3.20] 1.850 [47.00] .559 [14.20] 3/4-20 UNEF
16S 1.240 [31.50] 1.079 [27.40] .563 [14.30] .126 [3.20] 1.850 [47.00] .559 [14.20] 7/8-20 UNEF
16 1.240 [31.50] 1.079 [27.40] .563 [14.30] .126 [3.20] 2.283 [58.00] .748 [19.00] 7/8-20 UNEF
18 1.358 [34.50] 1.213 [30.80] .657 [16.70] .157 [4.00] 2.283 [58.00] .748 [19.00] 1-20 UNEF
20 1.476 [37.50] 1.346 [34.20] .780 [19.80] .157 [4.00] 2.283 [58.00] .748 [19.00] 1 3/16-18 UNEF
22 1.594 [40.50] 1.472 [37.40] .780 [19.80] .157 [4.00] 2.323 [59.00] .748 [19.00] 1 3/16-18 UNEF
24 1.752 [44.50] 1.610 [40.90] 1.000 [25.40] .157 [4.00] 2.402 [61.00] .811 [20.60] 1 7/16-18 UNEF
28 1.969 [50.00] 1.839 [46.70] 1.063 [27.00] .157 [4.00] 2.638 [67.00] .811 [20.60] 1 7/16-18 UNEF
32 2.224 [56.50] 2.102 [53.40] 1.280 [32.50] .157 [4.00] 2.795 [71.00] .874 [22.20] 1 3/4-18 UNS
Dimensions are shown in Inches (mm).
SCPB01D* Non-environmental, less grommet
 SCPB01F*  Environmental with grommet
Shell
Size		 Front View Side View
Q
Max		 A
+.000[+0.00]
-.006[-0.15]		 K
±.008 [±0.2]		 L
Max		 M
+.016[+0.4]
-.000[-0.0]		 X
Min		 Y
Max
10SL .886 [22.50] .717 [18.20] .110 [2.80] 2.520 [64.0] .559 [14.20] .256 [6.50] .894 [22.70]
14S 1.161 [29.50] .969 [24.60] .126 [3.20] 2.717 [69.0] .559 [14.20] .354 [9.00] 1.083 [27.50]
16S 1.240 [31.50] 1.079 [27.40] .126 [3.20] 2.795 [71.0] .559 [14.20] .433 [11.00] 1.181 [30.00]
16 1.240 [31.50] 1.079 [27.40] .126 [3.20] 3.228 [82.0] .748 [19.00] .433 [11.00] 1.181 [30.00]
18 1.358 [34.50] 1.213 [30.80] .157 [4.00] 3.228 [82.0] .748 [19.00] .559 [14.20] 1.268 [32.20]
20 1.476 [37.50] 1.346 [34.20] .157 [4.00] 3.228 [82.0] .748 [19.00] .622 [15.80] 1.476 [37.50]
22 1.594 [40.50] 1.472 [37.40] .157 [4.00] 3.268 [83.0] .748 [19.00] .622 [15.80] 1.476 [37.50]
24 1.752 [44.50] 1.610 [40.90] .157 [4.00] 3.425 [87.0] .811 [20.60] .843 [21.40] 1.705 [43.30]
28 1.969 [50.00] 1.839 [46.70] .157 [4.00] 3.661 [93.0] .811 [20.60] .843 [21.40] 1.705 [43.30]
32 2.224 [56.50] 2.102 [53.40] .157 [4.00] 3.898 [99.0] .874 [22.20] 1.051 [26.70] 2.035 [51.70]
Dimensions are shown in Inches (mm).
CRBS01K* Environmental, less grommet


Shell
Size

 Front View Side View
Q
Max		 A
+.000[+0.00]
-.006[-0.15]		 K
±.008[±0.2]		 L
Max		 M
+.016[+0.4]
-.000 [-0.0]		 Z
Open Closed
10SL .886 [22.50] .717 [18.20] .110 [2.80] 2.874 [73.0] .559 [14.20] .312 [7.93] .094 [2.38]
14S 1.161 [29.50] .969 [24.60] .126 [3.20] 3.031 [77.0] .559 [14.20] .438 [11.12] .230 [5.84]
16S 1.240 [31.50] 1.079 [27.40] .126 [3.20] 3.031 [77.0] .559 [14.20] .531 [13.48] .315 [8.00]
16 1.240 [31.50] 1.079 [27.40] .126 [3.20] 3.465 [88.0] .748 [19.00] .531 [13.48] .315 [8.00]
18 1.358 [34.50] 1.213 [30.80] .157 [4.00] 3.583 [91.0] .748 [19.00] .625 [15.87] .378 [9.60]
20 1.476 [37.50] 1.346 [34.20] .157 [4.00] 3.583 [91.0] .748 [19.00] .748 [19.00] .445 [11.30]
22 1.594 [40.50] 1.472 [37.40] .157 [4.00] 3.622 [92.0] .748 [19.00] .748 [19.00] .445 [11.30]
24 1.752 [44.50] 1.610 [40.90] .157 [4.00] 3.819 [97.0] .811 [20.60] .937 [23.80] .610 [15.50]
28 1.969 [50.00] 1.839 [46.70] .157 [4.00] 4.055 [103.0] .811 [20.60] .937 [23.80] .610 [15.50]
32 2.224 [56.50] 2.102 [53.40] .157 [4.00] 4.449 [113.0] .874 [22.20] 1.250 [31.75] .921 [23.40]
Dimensions are shown in Inches (mm).
